Bridging the Gap Between Android Native Functionality and JavaScript Web Applications

I’ve been recently working on a project which requires some native Android capabilities that are not accessible within a JavaScript WebView context. There are projects such as Capacitor which help to bridge this gap. However, similar to my previous post, I already have an existing Kotlin application that I wished to include this functionality in.

To provide bi-directional communication between the JavaScript application running within the WebView and the native functionality available within the wrapper application, I built a thin bridge placed in the middle. In this post, I wish to provide an example pattern I have been using which handles the typical asynchronous lifecycle of the given functionality.

Bridging the Gap

To set up the bridge between the native Kotlin wrapper application and the JavaScript web application, you must supply an instance of a class which exposes functions that have been annotated with @JavascriptInterface.

Unlike the Swift equivalent, these functions are automatically exposed based on the presence of this annotation and also provide a means of returning synchronous results. As such, for this example I have included both a synchronous hasWifiPermissions and contrived asynchronous getCurrentWifiSsid example. It is contrived as the getCurrentWifiSsid example could have been made synchronous, but like the previous post which documented the iOS/Swift approach, I wanted to document a like-for-like comparison.

class WebBridge(private val context: Context) {

    @JavascriptInterface
    fun hasWifiPermissions(): Boolean {
        return ContextCompat.checkSelfPermission(context, ACCESS_FINE_LOCATION) == PERMISSION_GRANTED
    }

    @JavascriptInterface
    fun getCurrentWifiSsid(requestId: String) {
        if (!hasWifiPermissions()) {
            evaluateJavascriptWithinWebView("onGetCurrentWifiSsidResult('$requestId', null, 'Does not have sufficient WiFi permissions')")
            return
        }

        val wifiManager = context.applicationContext.getSystemService(Context.WIFI_SERVICE) as android.net.wifi.WifiManager
        val ssid = wifiManager.connectionInfo?.ssid

        if (ssid == null || ssid == "<unknown ssid>") {
            evaluateJavascriptWithinWebView("onGetCurrentWifiSsidResult('$requestId', null, null)")
        } else {
            evaluateJavascriptWithinWebView("onGetCurrentWifiSsidResult('$requestId', '${ssid.replace("\"", "")}', null)")
        }
    }

    private fun evaluateJavascriptWithinWebView(js: String) {
        if (context !is Activity) {
            return
        }

        val webView = context.findViewById<android.webkit.WebView>(R.id.webView)
        webView?.post {
            webView.evaluateJavascript(js, null)
        }
    }
}

This class is then instantiated and registered with the given WebView like so:

class MainActivity: ComponentActivity() {
    private lateinit var webView: WebView

    @SuppressLint("SetJavaScriptEnabled")
    override fun onCreate(savedInstanceState: Bundle?) {
        // ..

        webView = findViewById(R.id.webView)
        webView.settings.javaScriptEnabled = true
        webView.addJavascriptInterface(WebBridge(this), "WebBridge")
    }
}

Although there is support for synchronous invocation of native behaviour, I wanted to provide a unified public API which could be used for bridging between both iOS and Android applications. As such, I opted to use the Promise construct to abstract away the implementation details of whether the call can or cannot be made synchronously.

const requests = {};

export const getCurrentWifiSsid = () =>
  new Promise((resolve, reject) => {
    const requestId = Date.now().toString();
    requests[requestId] = { resolve, reject };
    window.WebBridge.getCurrentWifiSsid(requestId);
  });

window.onGetCurrentWifiSsidResult = (requestId, ssid, error) => {
  if (error) {
    requests[requestId].reject(error);
  } else {
    requests[requestId].resolve(ssid);
  }
  delete requests[requestId];
};

export const hasWifiPermissions = () =>
  Promise.resolve(window.WebBridge.hasWifiPermissions());

To manage the asynchronous getCurrentWifiSsid function call, we create a requestId within the JavaScript bridge code, storing the Promise’s resolve and reject callbacks in a shared space which can be looked up by this requestId at a later time. We then invoke the WebBridge function on the native wrapper application, including all desired parameters (including this requestId). Upon completion of the native application’s behaviour, a separate JavaScript bridge function is invoked which supplies the requestId along with any additional parameters. The JavaScript bridge is then able to look up and invoke the Promise’s resolve and reject callbacks accordingly with the desired resulting values.

Aside: we could additionally include a timeout which rejects the Promise after a given time if we do not receive a result back from the native wrapper in a sufficient amount of time.
